GAC-UDF-10 - 10" x 2.5" GAC Carbon Filter - Reverse Osmosis Water Filter

产品介绍

I. Product Overview



Product Name: Water Purification Filter Cartridge GAC10



Product Type: Granular Activated Carbon (GAC) Filter Cartridge



Primary Function: Adsorbs residual chlorine, unpleasant odors, organic matter, and other impurities from water.



Applications: Pre-filtration for household water purifiers, pre-treatment for commercial water purification systems, etc.

 截屏2025-02-19 13.48.18.png

II. Product Features



Highly Efficient Adsorption: Utilizes premium coconut shell activated carbon with strong adsorption capacity, effectively removing residual chlorine, unpleasant odors, organic matter, and other impurities from water.



High-Flow Design: 10-inch large size increases the contact area between water and activated carbon, enhancing filtration efficiency and extending service life.



Safe and Eco-Friendly: Made from food-grade materials, complies with national drinking water hygiene standards, safe and non-toxic, ensuring peace of mind during use.



Easy Installation: Standard 10-inch universal filter cartridge, simple and convenient to install and replace.





Product Advantages



Compared to similar products on the market, GAC10 offers higher cost-effectiveness.



Undergoes strict quality testing to ensure stable and reliable product performance.



Provides comprehensive after-sales service to address your concerns.


产品参数

Technical Specifications



Material: Coal-based activated carbon / Coconut shell activated carbon



1. Dimensions: 10 inches (254 mm)



Length: 10 inches (254 mm), standard universal size with strong compatibility.



Outer Diameter: Typically around 63 mm, specific dimensions depend on the filter housing specifications.



Inner Diameter: Typically around 28 mm, specific dimensions depend on the filter housing specifications.



2. Filtration Accuracy: 5 microns



Filtration Accuracy: 5 microns, effectively filters out large particles such as sediment, rust, and colloids from water.



Filtration Efficiency: 95%, high filtration efficiency ensures water quality.



3. Recommended Flow Rate: 2-3 L/min



Flow Rate: 2-3 L/min, meets daily household water demand.



Water Pressure: 0.1-0.4 MPa, recommended operating pressure range to ensure filtration performance and service life.



4. Recommended Replacement Cycle: 3-6 months



Replacement Cycle: 3-6 months, specific replacement interval depends on local water quality and usage frequency.



Influencing Factors: Poorer water quality and higher water consumption shorten the replacement cycle.



Replacement Reminder: Some water purifiers are equipped with filter replacement reminder functions, allowing timely replacement based on prompts.



Other Technical Specifications:



Operating Temperature: 5-45°C, avoid use at excessively high or low temperatures.



Operating Pressure: 0.4 MPa, avoid excessive water pressure that may damage the filter cartridge.
